Engine (Mixer truck) |
Model | C13-380 (Carterpillar) |
| Type | Four-stroke, water-cooled | |
| in-line, four valves, direct injection | ||
| Max. Power | 283kw (2100rpm) | |
| Max. Torque | 1966 N.M (1200rpm) | |
| No. of Cylinder | 6 | |
| Bore * Stroke | 130*157 (mm) | |
| Displacement | 12.5L | |
| Controller type | Mechanical automation | |
| Air cleaner | Dry | |
| Accessories | Air conditioner,Mp3, imported steering device | |
|
Transmission (Mixer truck) |
Model | 9JS200T |
| Type | Mechanical (synchronizer) | |
| 1st | 14.05 | |
| 2nd | 8.38 | |
| 3rd | 6.22 | |
| 4th | 4.57 | |
| 5th | 3.40 | |
| 6th | 2.46 | |
| 7th | 1.83 | |
| 8th | 1.34 | |
| 9th | 1.00 | |
| Reverse | 14.05 | |
| Wheels & Tires | Rim | 8.0-20 |
| Tires | 11.0-20 | |
|
Axles (Mixer truck) |
Front | Stub axle, double T-cross section |
| Rear | Single reduction | |
| hub reduction & final drive ratio: 5.73 | ||
|
Brake systems (Mixer truck) |
Service | Full air brake, Dual circuit |
| Parking | Spring actuator at rear wheels | |
| Auxiliary | Exhaust brake | |
|
Fuel tank (Mixer truck) |
Mounted on offside of the frame | |
| Capacity | 350L | |
| Material | Galvanized steel | |
|
Steering (Mixer truck) |
Driving position | Left hand drive |
| Type | Recirculation ball with integral power, oil-assisted | |
| Model | HITACHI | |
|
Suspension (Mixer truck) |
Front | Tapered leaf spring, with 9 semi-elliptic shape |
| Rear | Tapered leaf spring, with 12 semi-elliptic shape | |
|
Clutch (Mixer truck) |
Type | Hydraulic control, air-assisted |
| Plate diameter | Dry single plate with diaphragm | |
| Outside diameter | 430 mm | |
|
Dimension (Mixer truck) |
Overall dimension | 9680*2495*3850 (mm) |
| Effective Capacity | 10m3 | |
| Kerb mass | 14000kg | |
| Number of axle | 4 | |
| Tread | 2065/2065/1860/1860 (mm) | |
| Wheelbase | 1850+3370+1350 (mm) | |
| Min. Ground clearance | 255mm | |
| No. of Seat | 3 | |
| Weight | GVW | 38000 kg |
|
Electrical system (Mixer truck) |
Batteries | 12 V (No. 2) |
| 150 A (No. 2) | ||
| Alternator | 24 V / 70A | |
| Starter | 24 V / 7.80kw | |
| Calculated performance | Max. Speed | 75 km/h |
| Max. Grade ability | 30 % | |
|
Frame (Mixer truck) |
Type | Parallel, tapered channel section type |
| (reinforced by stiffeners and cross members) | ||
| Width (Front / Rear) | 940/850 (mm) | |
