Description
CAMC is the sole brand to be treated as the model in heavy duty industry twice. 8×4 self-unloading truck is extensively used in engineering, mining, urban construction, transportation and other places. It is typically used for delivery of various building materials including ash, sand, stone, soil and other bulk materials. This tipper truck can also be used to transport mine, ore and coal. With annual production capacity of 100,000 self-unloading trucks, we have already formed the high-end series 8×4 dump trucks represented by Xingkaima, the middle and high-end series products represented by CAMC heavy dump truck and the middle-end series products represented by CAMC Star. Our tipper trucks are able to satisfy customers’ different demands both home and abroad.
Features of 8×4 Self-Unloading Truck
1. Our company has a professional R & D team for manufacturing CAMC dump trucks. They are well received by our customers all over the world.
2. This tipper truck is featured with outstanding power performance, economical efficiency, reliability and environmental protection.
3. CAMC 8×4 self-unloading truck possesses compact structure, strong load capacity, strong power, stable performance and higher market awareness.
4. This tipper truck can adapt to harsh environments of construction site and mining area.
Technical Specifications of 8×4Self-Unloading Trucks
| Product Name | Dump Truck | |
| Product Model | HN3310P34B8M3 | |
| Place of Origin | Maanshan, Anhui, China | |
| Kerb Mass | 14 ton | |
| Rated Payload | 40-60 ton | |
| Drive Type | Left-Hand (Optional RHD) | |
| Drive Model | 8 × 4 | |
| Vehicle Body Color | Yellow (optional) | |
| Overall Dimension (L × W × H) mm | 9000 × 2495 × 3340 | |
| Body Interior (mm) | 6200 × 2300 × 1200 | |
| Engine | Brand | DONGFENG CUMMINS |
| Model | L340 30 | |
| Max. Power (kw/r/min) | 375/2200 | |
| Max. Torque (N. m/r/min) | 1480/1400 | |
| No. of Cylinder | 6 | |
| Bore × Stroke (mm) | 114 × 145 | |
| Displacement | 8900 ml | |
| Control Type | Mechanical | |
| Air Cleaner | Dry Paper Element | |
| Emission Standard | Euro II | |
| Clutch | Type | Hydraulic Control with Air Assisted |
| Plate Diameter | Dry Single Plate with Diaphragm Outside Diameter: 430 mm | |
| Transmission | Brand | FAST GEAR |
| Model | RT-11509C (9-speed & 1-reverse) | |
| Type | Mechanical | |
| The Number of Axles | 4 | |
| Rear Axle (Drive Axle)-Load | 16000 kg × 2 | |
| Front Axle-Load | 7500 kg × 2 | |
| Cabin Type | Classic Flat-Roof (Optional EF, CH, EH) | |
| Cabin | With A/C, Radio, MP3, Bunk | |
| Brake System | Service | Full Air Brake Dual Circuit |
| Parking | Spring Actuator at Rear Wheels | |
| Auxiliary | Exhaust Break | |
| Steering System | Recirculation Ball with Integral Power Assisted by Oil | |
| Wheelbase (mm) | 1850+2850+1350 | |
| Wheel/Tire | Type | Bias/Radial Tube/Radial Tubeless |
| Model (Optional) | 11.00-20/11.00R20/11R22.5 12.00-20/12.00R20/12R22.5 | |
| Tire Number | 12+1 | |
| Fuel Tank | Volume (L) | 350 |
| Body Steel Thickness | Bottom: 8 mm; Side: 5 mm | |
| Body Lifting System | Hydraulic Front Lift | |
| Front Overhang/Rear Overhang (mm) | 1370/1000 | |
| Approach/Departure Angle (°) | 24/23 | |
| No. of Steel Spring (Front/Rear) | 9/12 | |
| Max. Speed (km/h) | 75 | |
Auhui Hualing Automobile Co., Ltd is a leading supplier and exporter of self-unloading trucks in China. In addition to tipper truck, our products also cover tractor truck, cargo truck, mixer truck, special vehicle chassis, heavy axle, and so on. As one of the first batch of enterprises of National Automobile Export Base and the fourth batch of Innovation-Oriented Technical Experimental Enterprises under Ministry of Science and Technology, our company possesses the enterprise technological center, postdoctoral scientific research workstation approved by the state, first-class complete and parts research and development facilities and four international advanced production lines. Our 8×4 self-unloading trucks are exported to more than 60 nations and regions, such as Eastern Europe, North Africa, the Middle East, Central Asia, Southeast Asia, South America, etc.
